5309 Instruction Book – 1977 Evinrude 85–115 HP (Models 85793, 85799, 115793 & 115799)
$45.00
In stock
The 5309 Evinrude Service Manual stands as the authentic OEM factory-issued guide for 1977 Evinrude outboard motors within the 85–115 HP range, covering models 85793, 85799, 115793, and 115799. Designed for skilled technicians and passionate DIYers, it delivers accurate, factory-approved instructions.
Why It Matters:
Created in 1976 for the 1977 model year, this manual equips you with precision-engineered content—from system diagrams to torque charts and troubleshooting workflows—ensuring maintenance tasks follow the original manufacturer’s standards.
Manual Structure:
-
Introduction & Service Overview
-
General Service Information
-
Fuel System
-
Ignition System
-
Power Head
-
Lower Unit
-
Electrical System
-
Remote Control
-
Power Trim & Tilt
Every chapter features easy-to-follow steps, annotated diagrams, spec tables, and diagnostic tips to resolve complex issues swiftly
Arizona Outboard Dismantlers offers this 5309 Evinrude Service Manual as a dependable resource with verified authenticity, trusted both by professional mechanics and vintage marine enthusiasts.
Additional information
| Weight | 500 g |
|---|---|
| Dimensions | 29 × 25 × 3 cm |
